410 Stainless Steel Plate
DSM
1.4006
410
SUS410
12Cr13
tweezers and forceps
|
| |
410 Stainless Steel Plate Specification
| Product | 410 Stainless Steel Plates |
| Grade Equivalents | 410, 1.4006,UNS S41000 |
| Thickness (mm) | 6mm to 50mm |
| Width (mm) | 1250mm,1500mm,2000mm,Custom Width |
| Length (mm) | 2000mm,2500mm, Custom Length |
| Finish | 2B,No.4, BA,NO.1(HRAP),Custom Polish |
| Standard Coating | Paper Interleaf |
| Services | Shearing.Cutting. Blanking. Circles, Punching |
Hardness of 410 Stainless Steel plate
| Heat Treatment | T410 (0.14%C) Hardened 1800°F (982°C) | ||
|---|---|---|---|
| Rockwell Hardness | 0.2% YS, Ksi (MPa) | UTS, Ksi (MPa) | |
| Annealed* | 81 HRB | 45.4 (313) | 80.4 (554) |
| Hardened & Tempered 400°F (204°C) | 43 HRC | 156.1 (1076) | 202.9 (1399) |
| Hardened & Tempered 550°F (288°C) | 40 HRC | 148.3 (1022) | 187.0 (1289) |
| Hardened & Tempered 600°F (316°C) | 40 HRC | 148.8 (1026) | 186.1 (1283) |
| Hardened & Tempered 800°F (427°C) | 41 HRC | 132.9 (916) | 188.5 (1300) |
| Hardened & Tempered 900°F (482°C) | 41 HRC | 122.6 (845) | 154.3 (1063) |
| Hardened & Tempered 1000°F (538°C) | 35 HRC | 127.9 (882) | 154.3 (1063) |
| Hardened & Tempered 1200°F (649°C) | 98 HRB | 85.5 (589) | 111.2 (767) |
Applications of 410 Stainless Steel plate
410 Stainless Steel plate is ideal for applications that require moderate corrosion resistance with high mechanical properties. 410 Stainless Steel plate is used in the following applications:
Cutlery
Gas turbines and steam turbine blades
Kitchen utensils
Bolts and nuts
Pump parts and shafts
Mine ladder rugs
Dental and surgical instruments
Nozzles
Hardened steel seats and balls for oil well pumps
