0Cr21Al6
-
-
-
0Cr21Al6
Electric heating elements
|
| |
0Cr21Al6 is a high-resistivity Fe-Cr-Al (Iron-Chromium-Aluminum) alloy, composed of approximately 21% chromium and 6% aluminum, with the balance being iron. This alloy is known for its excellent oxidation resistance, high electrical resistivity, and outstanding performance at elevated temperatures, making it ideal for use in electric heating elements.
0Cr21Al6 exhibits a maximum operating temperature of up to 1300°C, suitable for both industrial and household heating applications. Compared to Ni-Cr alloys, it offers a longer service life, lower density, and lower material cost, making it a cost-effective and high-performance heating solution.
Chemical Composition
| C % | Si % | Mn % | P % | S % | Cr % | Al % |
| ≤0.05 | ≤0.60 | ≤0.50 | ≤0.025 | ≤0.020 | 21.0-23.0 | 5.0*-7.0 |
Physical properties
Resistivity Ω.m,20℃ | Density g/cm3 | Thermal conductivity KJ/m.h.℃ | Linear expansion coefficient α×10-6/℃ | Melting point ℃ | Maximum operating temperature ℃ |
| 1.42 | 7.16 | 63.2 | 14.7 | 1500 | 1250 |
0Cr21Al6 Product Features:
①High operating temperature and good heat resistance
② Low price (no nickel element).
③ In an oxidizing atmosphere, it has good oxidation resistance and a longer service life than nickel-chromium alloy.
④ High resistivity and low specific gravity, and can withstand a large watt load per square centimeter at the operating temperature.
⑤ Strong resistance to oxygen, sulfur and hydrogen.
Application:
Electric furnaces and kilns
Heating elements in household appliances (toasters, ovens, air heaters)
Resistors and load banks
Infrared heating devices
Industrial drying and heating systems
Product specifications provided by DSM
| Grade | Classification | Available thickness specifications/mm |
| 0Cr21Al6 | hot colled coil | 3.0-3.5 |
| Cold rolled sheets, strips | 0.03-1.0 |
