321
DSM
1.4541
321
SUS 321
06Cr18Ni11Ti
High-Temperature Applications, Chemical Processing, Food Processing, Automotive
Combines the excellent corrosion resistance of 304 stainless steel with the high temperature resistance of 309 stainless steel. It is more resistant to intergranular corrosion than 304 stainless steel due to its stabilization with titanium.
Overall, 321 stainless steel is valued for its combination of corrosion resistance, heat resistance, and weldability, making it suitable for a variety of high-temperature and corrosive environments.
Chemical Composition
| C≤% | Si≤% | Mn≤% | P≤% | S≤% | Ni≤% | Cr % |
| 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 9.00-13.00 | 17.00-19.00 |
Mechanical properties
| Tensile strength(Min) | Yield Strength(Min) | Elongation(Min)% | Hardness(Max) | ||
| Mpa | Mpa | 50mm | HBW | HRB | HV |
| 520 | 205 | 40 | 187 | 90 | 200 |
Application
Aerospace and Aircraft Components
Heat Exchangers
Welding Applications
Cryogenic Equipment
Supply size
Thickness: Min 0.2mm
Width: 8-25mm
Spool width: Max 350mm
Single weight: Max 600kgs
Inside diameter: 300-400mm
Outside diameter: Max 750mm
