321
321 stainless steel strip is a titanium-stabilized austenitic stainless steel known for its excellent corrosion resistance and high-temperature strength.
Chemical Composition
| C≤% | Si≤% | Mn≤% | P≤% | S≤% | Ni≤% | Cr % |
| 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 9.00-13.00 | 17.00-19.00 |
Standards
EU EN | JAPAN JIS | China GB | USA ---- |
| 1.4541 | SUS 321 | 06Cr18Ni11Ti | 321 |
Mechanical properties
| Tensile strength(Min) | Yield Strength(Min) | Elongation(Min)% | Hardness(Max) | ||
| Mpa | Mpa | 50mm | HBW | HRB | HV |
| 520 | 205 | 40 | 187 | 90 | 200 |
Application
Aerospace and Aircraft Components
Heat Exchangers
Welding Applications
Cryogenic Equipment
Supply size
Thickness: 0.05-1.2mm
width:4.2-775mm
length:coil type or it can be produced as customer requirements
surface:DSM offers a variety of different surface treatments for stainless steel plates. There are1U, 1C, 1D, 1E, 2B, BA, No.4, TR, HL etc.
Inner Diameter: 300、400、500（Customized according to the customer's machine size）
Outer diameter: The outer diameter range is determined based on the width of the material required by the customer and the maximum weight of a single trailer.
Edge: The edge of the steel strip is trimmed, and the burr height is 10% mm. If there are special requirements for the edge, it can be scraped.
