4Cr13
DSM
1.4034
-
-
40Cr13
Higher hardness than 30Cr13 after quenching, used as cutting tools, nozzles, valve seats, valves, etc.
1.4034 stainless steel is a martensitic stainless steel, also known as X46Cr13, which complies with EN 10088 and is often used in applications that require high hardness and corrosion resistance.
Chemical Composition
| Grade | C≤% | Si≤% | Mn≤% | P≤% | S≤% | Cr % |
| 1.4034 | 0.43-0.5 | 1.00 | 1.00 | 0.040 | 0.015 | 12.50-14.50 |
Mechanical Properties
| Tensile Strength | Yield Strength | Elongation | Hardness | |
| Max (Mpa) | Min (Mpa) | Min% 50mm | HRB | HV |
| 780 | 205 | 12 | 99 | 245 |
Application
Knives and scissors
Medical devices
Automotive industry
Food industry
Precision machinery
Supply Form
Thickness: 0.04-30mm
Width: 14-2000mm
Length: can be customized according to customer requirements
Surface
DSM offers a variety of different surface treatments for stainless steel plates. There are1U, 1C, 1D, 1E, 2B, BA, No.4, TR, HL etc.
Edge
The edge of the steel strip is trimmed, and the burr height is 10% mm. If there are special requirements for the edge, it can be scraped.
Label
The label on each pallet shows the relevant material information, including coil number, steel type, size, net weight, etc.; it is convenient for customers to count the goods.
